Cup heat shrink packaging machine

Cup heat shrink machine is suitable for group packaging of food, medicine, beverages, bowl noodles, milk tea, mosquito coils, wallpaper, exercise books, filters, electrical switches, plastic wrap, garbage bags, various stationery, industrial parts and daily necessities Cosmetic body packaging, etc.

Features:

■ Single or arbitrary packaging.

■ Anti-cutting safety clutch device will not damage the package.

■ Increase the waste recycling device to make the packaging more beautiful, saving about 3%-10% of materials compared with the traditional quality cup packaging machinery.

■ Color touch screen control system, easy to operate and beautiful in appearance; PLC control makes the system more stable, reliable and has low failure rate; bag length, speed and temperature can be adjusted individually, easy and accurate to operate.

■ Can be equipped with printer or inkjet printer, no need for labor.

■ With motor brake control, the equipment is responsive.

■ High-efficiency dual-temperature zone of heat shrinkable furnace, high-efficiency hot air circulation, automatic temperature control, to ensure shrinkage quality.

Features of heat shrink:

1. Adopt imported digital intelligent dual-display temperature controller;

2. There is an interlayer in the middle of the heating area of the furnace body, and the interior is filled with thermal insulation materials, which can effectively save energy;

3. The whole furnace cavity is divided into two temperature zones, the front and the back, and the temperature is controlled separately;

4. The hot air is forced to circulate and heat, and the upper and lower sides are heated evenly;

5. The conveyor belt can be equipped with different packaging materials: stainless steel mesh belt, Teflon mesh belt, roller chain, etc., the speed can be adjusted steplessly;

6. It is suitable for shrinking of various packaging materials such as POF, OPP, PVC, etc. The effect is beautiful and uniform after shrinking;

7. Maximum package size: width 200mm, height 150mm;

8. The total power of the YHR type heat shrinkable furnace is 16.1KW, of which the thermal power is 15KW and the motor power is 1.11KW;

9. Dimensions: Length 2.41M; Width 0.6M; Height 1.6M;

10. The machine can be used in conjunction with HP heat shrink packaging machine, or it can be used alone to shrink larger volume boxes.
